Original: $3,217.00
-70%$3,217.00
$965.10The Story
Overview
SHEL LAB Gravity Convention Laboratory Ovens are recommended for critical scientific and analytical use in laboratory and pilot plant product research. Typical applications include aging, curing, drying, baking, pre-heating, conditioning and life cycle testing.
Choose from three cabinet sizes, each with gravity convection and reserve heating power for quick recovery after door openings.
Features:
- Microprocessor Controls
- Superb Temperature Control
- Cool Touch Damper
- Digital Timer to 99hr and 59 min
- CE Approved
- 2 Shelves
- 24 Month Limited Warranty
Key Attributes
|
Max Temperature |
306°C |
|
Max Capacity |
1.4, 3, or 4.9 cu ft |
|
Air Movement |
Natural |
|
Electrical |
110-120 VAC |
| Warranty | 2 years |
Manufacturer Specifications
| MODEL | SGO1 | SGO3 | SGO5 |
|
PART ID
|
SLG122 | SLG322 | SLG522 |
|
EXTERIOR DIMENSIONS (W × D × H)
|
22.7 x 23.5 x 31.5 | 26.9 x 28.6 x 34 | 31.4 x 28.1 x 38.8 |
|
INTERIOR DIMENSIONS (W × D × H)
|
12.1 x 13.7 x 14.5 | 16.5 x 19.5 x 16.2 | 21 x 19.4 x 20.7 |
|
VOLUME
|
1.4 cu.ft. (39.4 L) | 3.0 cu.ft. (85.0 L) | 4.9 cu.ft. (138 L) |
|
SHELF DIMENSIONS (W × D)
|
11.9 x 13.6 (302 mm × 345 mm) | 16.1 x 18.8 (409 mm × 478 mm) | 20.6 x 18.8 (523 mm × 478 mm) |
|
UNIT WEIGHT
|
126.5 lbs (57.4 kg) | 170.5 lbs (77.3 kg) | 208 lbs (94.3 kg) |
|
INTERIOR METAL
|
430 SST | 430 SST | 430SST |
|
EXTERIOR METAL
|
Painted Cold Roll Steel | Painted Cold Roll Steel | Painted Cold Roll Steel |
|
OPERATING TEMPERATURE RANGE
|
Amb +20 - 306C | Amb +20 - 306C | Amb +20 - 306C |
|
TEMPERATURE UNIFORMITY - MIDRANGE
|
3.5 °C | 3.5 °C | 3.5 °C |
|
TEMPERATURE STABILITY - MIDRANGE
|
0.3 °C | 0.3 °C | 0.3 °C |
|
CONTROLLER TYPE
|
Digital | Digital | Digital |
|
DISPLAY RESOLUTION
|
0.1 °C | 0.1 °C | 0.1 °C |
|
POWER VOLTAGE , FREQUENCY AND CURRENT
|
110-120 VAC, 50/60 Hz, 12.0 Amps | 110-120 VAC, 50/60 Hz, 14.0 Amps | 110-120 VAC, 50/60 Hz, 14.0 Amps |
|
SAFETY CERTIFICATIONS
|
UL 61010-1, EN 61010-1, CSA 61010-1, CE | UL 61010-1, EN 61010-1, CSA 61010-1, CE | UL 61010-1, EN 61010-1, CSA 61010-1, CE |
Details & Craftsmanship
Every detail has been carefully considered to bring you the perfect product.
Details & Craftsmanship
Every detail has been carefully considered to bring you the perfect product.
Details & Craftsmanship
Every detail has been carefully considered to bring you the perfect product.
Details & Craftsmanship
Every detail has been carefully considered to bring you the perfect product.
Description
Overview
SHEL LAB Gravity Convention Laboratory Ovens are recommended for critical scientific and analytical use in laboratory and pilot plant product research. Typical applications include aging, curing, drying, baking, pre-heating, conditioning and life cycle testing.
Choose from three cabinet sizes, each with gravity convection and reserve heating power for quick recovery after door openings.
Features:
- Microprocessor Controls
- Superb Temperature Control
- Cool Touch Damper
- Digital Timer to 99hr and 59 min
- CE Approved
- 2 Shelves
- 24 Month Limited Warranty
Key Attributes
|
Max Temperature |
306°C |
|
Max Capacity |
1.4, 3, or 4.9 cu ft |
|
Air Movement |
Natural |
|
Electrical |
110-120 VAC |
| Warranty | 2 years |
Manufacturer Specifications
| MODEL | SGO1 | SGO3 | SGO5 |
|
PART ID
|
SLG122 | SLG322 | SLG522 |
|
EXTERIOR DIMENSIONS (W × D × H)
|
22.7 x 23.5 x 31.5 | 26.9 x 28.6 x 34 | 31.4 x 28.1 x 38.8 |
|
INTERIOR DIMENSIONS (W × D × H)
|
12.1 x 13.7 x 14.5 | 16.5 x 19.5 x 16.2 | 21 x 19.4 x 20.7 |
|
VOLUME
|
1.4 cu.ft. (39.4 L) | 3.0 cu.ft. (85.0 L) | 4.9 cu.ft. (138 L) |
|
SHELF DIMENSIONS (W × D)
|
11.9 x 13.6 (302 mm × 345 mm) | 16.1 x 18.8 (409 mm × 478 mm) | 20.6 x 18.8 (523 mm × 478 mm) |
|
UNIT WEIGHT
|
126.5 lbs (57.4 kg) | 170.5 lbs (77.3 kg) | 208 lbs (94.3 kg) |
|
INTERIOR METAL
|
430 SST | 430 SST | 430SST |
|
EXTERIOR METAL
|
Painted Cold Roll Steel | Painted Cold Roll Steel | Painted Cold Roll Steel |
|
OPERATING TEMPERATURE RANGE
|
Amb +20 - 306C | Amb +20 - 306C | Amb +20 - 306C |
|
TEMPERATURE UNIFORMITY - MIDRANGE
|
3.5 °C | 3.5 °C | 3.5 °C |
|
TEMPERATURE STABILITY - MIDRANGE
|
0.3 °C | 0.3 °C | 0.3 °C |
|
CONTROLLER TYPE
|
Digital | Digital | Digital |
|
DISPLAY RESOLUTION
|
0.1 °C | 0.1 °C | 0.1 °C |
|
POWER VOLTAGE , FREQUENCY AND CURRENT
|
110-120 VAC, 50/60 Hz, 12.0 Amps | 110-120 VAC, 50/60 Hz, 14.0 Amps | 110-120 VAC, 50/60 Hz, 14.0 Amps |
|
SAFETY CERTIFICATIONS
|
UL 61010-1, EN 61010-1, CSA 61010-1, CE | UL 61010-1, EN 61010-1, CSA 61010-1, CE | UL 61010-1, EN 61010-1, CSA 61010-1, CE |
