MVP 10 basic Vacuum pump

For dry, oil-free applications

• Slimline, compact design and long service life
• Straightforward servicing and simple maintenance
• Diaphragm pump that is highly resistant to chemicals as all parts that come into contact with gas are made of PTFE or PTFE compounds

Manufacturer Specifications:

Pump rate max. (50/60Hz)	1.7 m³/h
Pump rate max. (50/60Hz)	28.3 l/min
Final pressure without gas ballast	8 mbar
Final pressure with gas ballast	15 mbar
Connection diameter suction side	10 mm
Suction levels	2
Connection diameter pressure side	10 mm
Gas ballast valve	yes
Input pressure min.	7 mbar
Input pressure max.	1050 mbar
Cylinder	2
Speed dependent pressure control	no
Speed range	1380 - 1680 rpm
Nominal speed	1380 rpm
Vacuum sensor	no
Venting valve	no
Condensate trap	no
Emission condenser	no
Noise at low. pressure	65 dB(A)
Dimensions (W x H x D)	9.6 x 6.1 x 12.6 in
Weight (lbs)	25.4
Permissible ambient temperature	10 - 40 °C
Permissible relative humidity	0.8
Protection class according to DIN EN 60529	IP 54
RS 232 interface	no
USB interface	no
Analog output	no
Voltage	230 / 115 / 100 V
Frequency	50/60 Hz
Power input	180 W
